ATEX/IECEx/KTL/PA and GB approved SP XCD flammable CAT 0-100% LEL (20 to 100% LEL, 10% LEL) with LM25, M20 entry
مشخصات فنی
8344457 Draeger Polytron 8200 Gas Detector
Model (مدل)
Polytron 8200
Part Number (شماره قطعه)
8344457
Sensor Type (نوع سنسور)
Catalytic Bead
Sensor Material (جنس محفظه سنسور)
Stainless steel 303
Detectable Gases (گازهای قابل سنجش)
flammable gases and vapors
Detection Range (بازه سنجش)
0 to 100%LEL
Response Time (T90) Secs (زمان پاسخ دهی در ثانیه)
***
Operating Voltage (ولتاژ عملکرد)
10 to 30 V DC, 3-wire
Power Consumption (توان مصرفی)
105 mA at 24 V, non-remote
Output (خروجی)
4 to 20 mA, HART
Operating Temperature (دمای قابل تحمل)
-40 to 80°C (-40 to 176°F)
Ingress Protection (حفاظت داخلی)
IP65/66/67, NEMA 4X & 7
Operating Humidity (رطوبت قابل تحمل)
0 to 100 %RH, non-condensing
Housing Material (جنس بدنه)
Epoxy coated copper-free aluminum or stainless steel SS316 L
Manufacture (سازنده)
Draeger
Entries (ورودی)
3/4" NPT threaded holes or M20 cable gland
Accuracy (دقت)
***
Certifications (گواهینامهها)
ATEX : II 2G Ex db e IIC T6/T4 Gb, -40 ≤ Ta ≤ +40/+80°C; II 2D Ex tb IIIC T80/130°C Db, CE markings ATEX (Directive 2014/34/EU) Electromagnetic Compatibility (Directive 2014/30/EU) Low Voltage (Directive 2014/35/EU), CSA, IECEx: Ex db e IIC T6/T4 Gb, -40 ≤ Ta ≤ +40/+80°C; Ex tb IIIC T80/130°C Db, UL
